Carbide
Tipped Brazed Tool Bits -- DIN & ISO |
| |
|
|
DIN4971-ISO1 |
|
 |
| Shank size |
K10/20(right) |
K10/20(left) |
P25/30(right) |
P25/30(left) |
| mm |
Model No. |
Model No. |
Model No. |
Model No. |
| 10*10*90 |
4971-0001 |
4971-1001 |
4971-2001 |
4971-3001 |
| 12*12*100 |
4971-0003 |
4971-1003 |
4971-2003 |
4971-3003 |
| 16*16*110 |
4971-0005 |
4971-1005 |
4971-2005 |
4971-3005 |
| 20*20*125 |
4971-0007 |
4971-1007 |
4971-2007 |
4971-3007 |
| 25*25*140 |
4971-0009 |
4971-1009 |
4971-2009 |
4971-3009 |
| 32*32*170 |
4971-0011 |
4971-1011 |
4971-2011 |
4971-3011 |
|
|
|
|
DIN4972-ISO2 |
|
 |
| Shank size |
K10/20(right) |
K10/20(left) |
K25/30(right) |
K25/30(left) |
| mm |
Model No. |
Model No. |
Model No. |
Model No. |
10*10*90 |
4972-0001 |
4972-1001 |
4972-2001 |
4972-3001 |
12*12*100 |
4972-0003 |
4972-1003 |
4972-2003 |
4972-3003 |
16*16*110 |
4972-0005 |
4972-1005 |
4972-2005 |
4972-3005 |
20*20*125 |
4972-0007 |
4972-1007 |
4972-2007 |
4972-3007 |
25*25*140 |
4972-0009 |
4972-1009 |
4972-2009 |
4972-3009 |
32*32*170 |
4972-0011 |
4972-1011 |
4972-2011 |
4972-3011 |
|
|
| |
|
DIN4973-ISO8 |
|
 |
| Shank size |
Min. Boring Dia |
K10/20 |
P25/30 |
| mm |
mm |
Model No. |
Model No. |
8*8*125 |
14 |
4973-0001 |
4973-2001 |
10*10*150 |
18 |
4973-0003 |
4973-2003 |
12*12*180 |
21 |
4973-0005 |
4973-2005 |
16*16*210 |
27 |
4973-0007 |
4973-2007 |
20*20*250 |
34 |
4973-0009 |
4973-2009 |
25*25*300 |
43 |
4973-0011 |
4973-2011 |
32*32*355 |
52 |
4973-0013 |
4973-2013 |
|
|
| |
|
DIN4974-ISO9 |
|
 |
| Shank size |
Min. Boring Dia |
K10/20 |
P25/30 |
| mm |
mm |
Model No. |
Model No. |
8*8*125 |
14 |
4974-0001 |
4974-2001 |
10*10*150 |
18 |
4974-0003 |
4974-2003 |
12*12*180 |
21 |
4974-0005 |
4974-2005 |
16*16*210 |
27 |
4974-0007 |
4974-2007 |
20*20*250 |
34 |
4974-0009 |
4974-2009 |
25*25*300 |
43 |
4974-0011 |
4974-2011 |
32*32*355 |
52 |
4974-0013 |
4974-2013 |
|
|
| |
|
DIN4975-ISO10 |
|
 |
| Shank size |
K10/20 |
P25/30 |
| mm |
Model No. |
Model No. |
| 16*10*110 |
4975-0001 |
4975-2001 |
| 20*12*125 |
4975-0003 |
4975-2003 |
| 25*16*140 |
4975-0005 |
4975-2005 |
| 32*20*170 |
4975-0007 |
4975-2007 |
|
|
| |
|
DIN4976-ISO4 |
|
 |
| Shank size |
K10/20 |
P25/30 |
| mm |
Model No. |
Model No. |
10*10*90 |
4976-0001 |
4976-2001 |
12*12*100 |
4976-0003 |
4976-2003 |
16*16*110 |
4976-0005 |
4976-2005 |
20*20*125 |
4976-0007 |
4976-2007 |
25*25*140 |
4976-0009 |
4976-2009 |
32*32*170 |
4976-0011 |
4976-2011 |
|
|
| |
|
DIN4977-ISO5 |
|
 |
| Shank size |
K10/20(right) |
K10/20(left) |
P25/30(right) |
P25/30(left) |
| mm |
Model No. |
Model No. |
Model No. |
Model No. |
16*16*110 |
4977-0001 |
4977-1001 |
4977-2001 |
4977-3001 |
20*20*125 |
4977-0003 |
4977-1003 |
4977-2003 |
4977-3003 |
25*25*140 |
4977-0005 |
4977-1005 |
4977-2005 |
4977-3005 |
32*32*170 |
4977-0007 |
4977-1007 |
4977-2007 |
4977-3007 |
|
|
| |
|
DIN4978-ISO3 |
|
 |
| Shank size |
K10/20(right) |
K10/20(left) |
P25/30(right) |
P25/30(left) |
| mm |
Model No. |
Model No. |
Model No. |
Model No. |
16*16*110 |
4977-0001 |
4978-1001 |
4978-2001 |
4978-3001 |
20*12*125 |
4978-0003 |
4978-1003 |
4978-2003 |
4978-3003 |
25*16*140 |
4978-0005 |
4978-1005 |
4978-2005 |
4978-3005 |
32*32*170 |
4978-0007 |
4978-1007 |
4978-2007 |
4978-3007 |
|
|
| |
|
DIN4980-ISO6 |
|
 |
| Shank size |
K10/20(right) |
K10/20(left) |
P25/30(right) |
P25/30(left) |
| mm |
Model No. |
Model No. |
Model No. |
Model No. |
| 10*10*90 |
4980-0001 |
4980-1001 |
4980-2001 |
4980-3001 |
| 12*12*100 |
4980-0003 |
4980-1003 |
4980-2003 |
4980-3003 |
| 16*16*110 |
4980-0005 |
4980-1005 |
4980-2005 |
4980-3005 |
| 20*20*125 |
4980-0007 |
4980-1007 |
4980-2007 |
4980-3007 |
| 25*25*140 |
4980-0009 |
4980-1009 |
4980-2009 |
4980-3009 |
| 32*32*170 |
4980-0011 |
4980-1011 |
4980-2011 |
4980-3011 |
|
|
| |
|
DIN4981-ISO7 |
|
 |
| Size |
K10/20(right) |
K10/20(left) |
P25/30(right) |
P25/30(left) |
| mm |
Model
No. |
Model
No. |
Model
No. |
Model
No. |
| 12*8*100*3 |
4981-0001 |
4981-1001 |
4981-2001 |
4981-3001 |
| 16*10*110*4 |
4981-0003 |
4981-1003 |
4981-2003 |
4981-3003 |
| 20*12*125*5 |
4981-0005 |
4981-1005 |
4981-2005 |
4981-3005 |
| 25*16*140*6 |
4981-0007 |
4981-1007 |
4981-2007 |
4981-3007 |
| 32*20*170*8 |
4981-0009 |
4981-1009 |
4981-2009 |
4981-3009 |
|
|
| |
|
DIN282-60° - ISO12 |
|
 |
| Size |
K10/20 |
P25/30 |
| mm |
Model No. |
Model No. |
10*10*100 |
2820-0001 |
2820-2001 |
12*12*110 |
2820-0003 |
2820-2003 |
16*16*125 |
2820-0005 |
2820-2005 |
20*20*140 |
2820-0007 |
2820-2007 |
25*25*160 |
2820-0009 |
2820-2009 |
32*32*180 |
2820-0011 |
2820-2011 |
|
|
| |
|
DIN283-60° - ISO13 |
|
 |
| Shank size |
Min Boring Dia |
K10/20 |
P25/30 |
| mm |
mm |
Model No. |
Model No. |
10*10*140 |
24 |
2830-0001 |
2830-2001 |
12*12*150 |
30 |
2830-0003 |
2830-2003 |
16*16*180 |
36 |
2830-0005 |
2830-2005 |
20*20*210 |
45 |
2830-0007 |
2830-2007 |
25*25*250 |
55 |
2830-0009 |
2830-2009 |
32*32*300 |
70 |
2830-0011 |
2830-2011 |
|
|
| |
|
DIN263 - ISO11 |
|
 |
| Shank size |
Min Boring Dia |
K10/20 |
P25/30 |
| mm |
mm |
Model No. |
Model No. |
10*10*140 |
25 |
2630-0001 |
2630-2001 |
12*12*150 |
30 |
2630-0003 |
2630-2003 |
16*16*180 |
40 |
2630-0005 |
2630-2005 |
20*20*210 |
50 |
2630-0007 |
2630-2007 |
25*25*250 |
60 |
2630-0009 |
2630-2009 |
32*32*300 |
85 |
2630-0011 |
2630-2011 |
|
|
| |
